Modules/ PSU

Power Supply Unit Details

Motherboard for carring a Raspberry Pi or Zero.
It also includes a 2X step down 24V/5V to power a raspberry and provide power to WIZcubes attached modules via Raspberry 40 pin connector.
One is used to power the Raspberry PI and the other to bring power to 40 pin connector, for more power "hungry" WIZcube applications.
In most cases one can be used for both.
With this type of contruction no more "power failure" sign on the screen.


Part of the GREENHOUSE project
Part of the HOME AUTOMATION project
Part of the CNC CONTROLLER project
Part of the MODBUS WIZCUBE CODESYS project

M10PS01-01 Bottom  Real Populated
Raspberry PI running CODESYS
